Solder Wire Traditional 63Sn/37Pb Alloy RoHS Lead-Free Soldering Wire No Clean Flux Core 1 Lb. Spools
NO-CLEAN SOLDER WIRE
|
|
|
Solder Wire Available in Leaded & Unleaded Alloys on
1 Lb. Spools
Available in .020"Dia. & 0.032" Dia. |
|
|
|
Highest
Quality
Solder Wire:
Exceeding all MIL-Standards, our
No Clean Solder Wire
has a no-clean flux core and is terrific for
all your PCB soldering including both thru-hole and
surface mount. Ideal for prototyping,
low-volume runs, and printed circuit board rework at
the bench. Order here securely below. |
|
|
|
Leaded &
Unleaded: You Choose!
Available in
both the traditional, classic 63Sn / 37Pb alloy and in a RoHS Compliant
Lead-Free
alloy.
Ships with MSDS docs. 2 Wire Diameters. You Choose! Both
alloys are
available in two
wire diameters: 0.032" for normal soldering tasks and a
0.020" for finer pitch soldering. |
|
|
|
|
|
|
|
|
| |
|
Technical
Data & Features |
Product: Classic Alloy No Clean Solder Wire
Alloy Composition: 63 Sn / 37Pb
Liquidus Temperature: 183°C or 361°F
Standards: IPC & MIL-Spec Compliant
Flux Core: No Clean
Very Low Post-Reflow Residue
IPC Compliant
Superb Wetting Properties
Enhances Thermal Transfer
Cleans With Most Solvents & Saponifier
Active Resin Based Speeds Soldering
Non-Conductive & Non-Corrosive
Applications: Ideal for PCB Soldering SMD's & Thru-Hole
Shelf Life: Indefinite When Properly Stored
Wire Diameters: 0.032" (General Soldering)
0.020" (Fine Pitch Soldering)
Package Format: 1 Pound of Coiled Wire on Spool
Other: Ships With MSDS Docs
|
|
|
|
Technical
Data & Features |
ZeroLead®: No-Clean, No-Lead Solder Wire
Alloy Composition: 96.5 Sn / 3 Ag / 0.5 Cu
Liquidus Temperature: 220°C or 428°F
Standards: RoHS Compliant. IPC & MIL-Spec Compliant
Flux Core: No Clean
Very Low Post-Reflow Residue
IPC Compliant
Superb Wetting Properties
Enhances Thermal Transfer
Cleans With Most Solvents & Saponifier
Active Resin Based Speeds Soldering
Non-Conductive & Non-Corrosive
Applications: Ideal for PCB Soldering SMD's & Thru-Hole
Shelf Life: Indefinite When Properly Stored
Wire Diameters: 0.032" (General Soldering)
0.020" (Fine Pitch Soldering)
Package Format: 1 Pound of Coiled Wire on Spool
Other: Ships With MSDS Docs
|
|
|
|
MoreDetails:
1-Pound Spool of No Clean Solder Wire |
|
|
|
| |
|
|
Cleaner Solder Joints:
The big advantage of our No Clean Solder Wire is the
visibly cleaner appearance after solder reflow is made.
In fact,
cleaning is not even required for most applications.
If cosmetic cleaning is required, the No Clean residue
is easily removed with most flux solvents or removers (Recommend:
Non-Flammable Flux Remover). |
|
|
|
Inert Property Requires No Cleaning:
Residue removal? Because nature of the cored
no-clean flux inside the solder wire, after the solder joint has cooled
and the residual flux is
"dry," it is virtually inert. In fact, removal
of the flux is not required as any residue is
nonconductive and non-corrosive.
The no clean flux
in the core is moisture and fungus resistant. Indeed,
any dried rosin residue
can actually insulate the surface from atmospheric corrosion.
Still, the residue is easily removed with most flux removers. |
|
|
|
|
|
|
|
|
|
| |
|
Popular
No-Clean Flux Core
is
a "first-choice"
with commercial, military, industrial and medical
electronic customers who refuse to compromise
quality.
No-clean formulations are superior to problematic water-soluble
solders which can set up white residue conditions on printed
circuit substrate pads. |
|
Drop In
Replacement for No Clean Soldering Applications:
Finally, our No Clean Solder Wire is a
drop-in replacement
for your no-clean operations. And whether you are
working with the traditional, classic tin/leader wire products deliver
quality solder
joints, excellent wetting properties, superb thermal
transfer during soldering and enhanced cosmetics or with the newer RoHS compliant lead-free
solder alloys, our no clean solder wire will fit your needs. |
|
|
|
|
|
|
|
|
 |
|
|
|
|
|
|
|
 |
|
|
|
|
|
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
