The New MFR Soldering & Rework System |
|
|
Your
All-In-One Solution!
Cartridge heater technology provides soldering and
rework performance to suit even the most demanding
SMT removal and placement applications. The
cartridges provide fast thermal performance and
respond quickly to the load demands. A small shaft
diameter provides access to tightly cramped rework
areas and enables the most difficult operations to
be performed effortlessly.
|
|
A Single Tool for Your
Thru-Hole and SMD Soldering and De-Soldering!
The Multi Functional System (MFR) features the
milestone SmartHeat™ technology with its
high-performance making it ideal for even the the most
difficult soldering tasks including lead-free
applications! The MFR Series also has an extensive
selection of heater tips for production soldering and
rework / repair tasks.
The MFR
features an "Auto Standby" and Auto-Off" functions to
enhance your tip/heater life when not the iron rests in
the cradle, but with motion-detection, the MFR powers up
instantly when needed.
The
system includes two ports in the power supply, soldering
and rework handpiece, workstand. |
|
|
|
|
TECHNICAL SPECIFICATIONS |
MFR-PTZ, MFR-SRC,
MFR-PST, MFR-STZ
Ambient Operating Temperature:10-
40°C
Maximum Enclosure Temperature:55°C
Input Line Voltage:100-
240 VAC, grounded circuit
Input Line Frequency:50/60
Hz
Power Consumption:65 Watts
max.
Output Power:
50 Watts max. at 22°C ambient temperature
Output Frequency:450 KHz
Power Cord 3-Wire:183cm
(18/3") SJT
Power Supply Dimensions w x d
x h:
122mm x 200mm x 152.5mm (4.8" x 8" x 6")
Agency Tested Per: IEC
61000-6-1,EC 61000-6-3, and UL499, FCC CFR Part
15
Tip-to-Ground Potential:<
2mV
Tip-to-Ground Resistance:<
2 ohms
Idle Temperature Stability:±
1.1°C in still air
Hand-piece Cable Length:
L=71cm (48"), burn proof, ESD safe
Connector:8-pin power
connector
Work Stand Dimensions w x d x
h:
100 mm x 200 mm x 100 mm (4" x 8" x 4") |
 |
|
|
|
|
|
|
MFR-SRC SOLDERING
& REWORK SYSTEM |
|
Part No. |
Description |
|
MFR-SRC |
Soldering and Rework System |
|
INCLUDES |
|
|
MFR-PS1K |
Two
Port Universal Voltage Power Supply |
|
MFR-HSR |
Soldering and Rework Hand-piece |
|
MFR-WSSR |
Soldering Work Stand |
|
|
|
|
|
MFR SERIES OF SOLDERING AND REWORK
SYSTEM
|
|
DESCRIPTION
|
ITEM #
|
PRICE
|
 |
Soldering and Rework System
|
MFR-SRC
|
$519.00
|
|
|
|
|
CLICK HERE to go directly to our easy-to-navigate and illustrated Product Directory. |
|
|
|
