GIGANTIC PREHEATING GRID: 32 Sq. In (220 Sq. cm)
ZT-1-MGS MEGA-GRID™ PRE-HEATER AIRBATH
Effective, Bottom-Side Convection Pre-Heating for PCB, Thru-Hole, SMD, SMT, QFN & BGA Rework & Repair
WITH 1,500 WATT POWER, 50 CFM AIR SUPPLY (1,415 Liters/Minute)
The Zephyrtronics' AirBath “bathes the circuit board in warm air to reduce thermal stresses to the board and its components.”
-- NASA Report, January 9, 2004

Powerful bottom-side preheat, smd, bga, hot air preheater, smt rework
Digital Mega Grid Series AirBath        TM
Our 50 CFM (1,415 Liters/Minute) Air Volume.
Our Digital ZT-1-MGS-DPU AirBath™ Delivers More Preheat Power Than Others in Its Class.

There's nothing like the ZT-1 Mega-Grid AirBath -- now known as "the mother of all PCB preheaters" --with its 32-square inch (220  sq. cm) pre-heating grid and 1,500 watts of power and 50 CFM (1,415  liters/minute) of preheat and cooling air volume. Its forced convection preheats PCB's up to 18" x 18" (45cm x 45cm). Unlike inferior IR systems, forced convection bathes the entire PCB with preheated air. IR Systems, with so many drawbacks, only preheat an area directly at the IR grid. AirBaths™ know no such limitations!

Developed by Zephyrtronics at the specific request from NASA in 2004, the ZT-1 Mega-Grid is now also available for your largest PCB's with high copper content, heat-sinks, large ground or back planes. What a workhorse!  The Mega-Grid's patented protected technology  is your effective solution for PCB preheating for prototyping or rework for thru-hole and SMD, BGA & QFN components and all in our world-famous, recognizable trademark pyramid design.



Our Mega-Grid AirBath with its powerful 50 CFM (1,415 liters/minute) of air supply and its 6.3" x 5" (16cm x 13cm) enormous heating grid delivers its forced-convection preheating power as needed for those "boards from hell" -- as many engineers like to say.  Beware of imitative pre-heaters with less than 13CFM (360 liters/minute) that crudely attempt to compensate for their lack of preheat air volume with higher temp settings. Remember: the glass transition of a FR-4 PCB is only 170°C. You don't want higher preheat temps, you want a higher volume of lower preheated (100°C to 170°C) air applied to your PCB's.

Loaded With Premium Features: The Mega-Grid gets into all the nooks and crannies of the PCB assembly where hot plates and IR pre-heaters can't go (more below).  It is ESD-safe; features illuminated indicator lights: blue: cooling; red: preheating. It is self-contained with an internal air supply (no hookups); and all inside a  durable steel housing for industrial use and long production life.

Rework, Repair,  PCB Soldering
Equipment & Tools

BGA & SMD
BGA Rework, SMD Rework, Hot Air Station

PCB Preheaters

PCB Preheaters, Bottom-Side Pre-heat

PCB Fixtures
PCB Fixture 3-Track

Fume Extractors

Flush Cutters

Hot Air Pencil
Hot AirPencil, SMD Soldering Station

The PasteRack
Solder, Paste, Storage, Rack

Auto Dispenser
Autotamic Dispenser for Dispensing Liquids, Pastes, Fluids, Epoxies and More

Hot Air Rework
Digital SMD Hot Air Soldering Rework Station

Quality Magnifiers
ESD Safe, Lighted Magnifier, Magnifying Lamp, Diopter, Bench

De-Soldering
DeSoldering Station, Digital DeSoldering Stations, Temperature Control DeSoldering, DeSolder, Rework, Thru-Hole, Repair, Through-Hole, Low Price

Vacuum Pick-Up
Vaccum Pick Up Tool, SMD, PCB

QFP Straightener
Topline, QFP Lead Straigtener

Solder Suckers
ESD Solder Sucker, DeSolder Suckers



ZT-1-MGS MEGAGRID DIGITAL PREHEATER

Description

Model

Price

Buy Now

Mega Grid Preheat

MEGA-GRID
 DIGITAL
AIRBATH
 50 CFM Air Power
(1,415 Liter/Min)
1,500 Watt Power

ZT-1-MGS-DPU-120
(120 Volt for the U.S., Canada & Mexico)

$3,850


ZT-1-MGS-DPU-230
(230 Volt For All Int'l Customers)

$3,850
